Усилитель низких частот Alpine MRV-M500 | 2-10 дюймов. Сабвуферы Alpine W10S4 мощностью 1500 Вт
- channel design: 1 Channel (Mono) Channel Design
- bass eq: Bass EQ Function
- rca output: Non-Fading Pre-Amp Output (4 Volts)
- subwoofer size: 10 inch
- channels: Mono
В избранное
Характеристики
channel design
1 Channel (Mono) Channel Design
bass eq
Bass EQ Function
rca output
Non-Fading Pre-Amp Output (4 Volts)
subwoofer size
10 inch
channels
Mono
power supply
MOSFET Power
input sensitivity
0.15 - 4.0 V (RCA Input)
pre-amp stage
Discrete Pre-Amp Stage
rms power ratings per channel into 4 ohms
300W RMS x 1 (14.4V at 1% THD+N) Per channel into 4 Ohms
eq equalizer
0 to +12dB, fc=50Hz Equalizer
amplifier type
Class-D (Digital) Amplifier
speaker-level inputs
4-channel Speaker Level Inputs
crossover frequency (lpf)
50 - 400 Hz, -24dB/oct. Crossover Frequency (LPF)
max power output ratings
1100 Watts Total Max Power Output
subwoofer watts rms
250 Watts RMS EACH
subwoofer peak power
750W peak EACH
dimensions
7-7/8" L x 7-7/8" W x 2-3/16" H
final outputs
Power MOSFET Final Outputs
input impedance
10k ohms Input Impedance
bass control remote
Remote Bass Control Ready (RUX-KNOB Not Included)
power requirements
14.4 V.DC (11-16V allowable)
gain control
Continuously Adjustable Gain Control
model
MRV-M500
power supply design
DC-DC PWM Power Supply
rms power ratings per channel into 2 ohms
500W RMS x 1 (14.4V at 1% THD+N) Per channel into 2 Ohms
rms power
500W
crossover
Variable Lowpass Filter Crossover
4 - 10 v
0.4 - 10 V (Speaker Level Input)
upc
744553203593
